360 Photo stuck and need help

[redserv]

Heya Guys I am trying to simply create a 360 photo to start sharing them on FB. I use the Mavic 3 OG to capture the photos- put them in Luminar Neo to stitch and then export as a Jpeg. The problem i have is that the final 360 photo comes out cylindrical the horizon is curved and I am not sure how to fix it. I just can rap my head around this. Can you guys help me with this? I have attached a 360 test photo that was stitched with LN



[GFields]

Doesn't Luminar Neo provide a Spirical output?



[PanoVolo]

try PanoVolo )



[Robert Prior]

It should be an equirectangular projection. I wonder if part of the problem is that the drone can't capture a zenith image, and the stitching software is cropping automatically. I use PTGUI Pro and always specify full spherical (360° x 180°).

If Luminar can't do that then you may need other software.

The image you uploaded is missing the zenith. The horizon should be dead centre, and it's not.



[redserv]

It should be an equirectangular projection. I wonder if part of the problem is that the drone can't capture a zenith image, and the stitching software is cropping automatically. I use PTGUI Pro and always specify full spherical (360° x 180°).

If Luminar can't do that then you may need other software.

The image you uploaded is missing the zenith. The horizon should be dead centre, and it's not.

Now this makes perfect sense and I think you are probably right. Before posting the photo of fb I use Exfix website to fix metadata and it always defaults on a cylindrical. It will never allow me to do equirectangular. With that said I will really like some recommendations to software I can use. PTGUI looks really good but the price is just too much ATM. I also don't want a subscription based software. I will appreciate your feedback. Thanks so much for helping. I was starting to get frustrated



[redserv]

Doesn't Luminar Neo provide a Spirical output?

I am not sure. The image I attached is what the final image is from LN



[Robert Prior]

Now this makes perfect sense and I think you are probably right. Before posting the photo of fb I use Exfix website to fix metadata and it always defaults on a cylindrical. It will never allow me to do equirectangular. With that said I will really like some recommendations to software I can use. PTGUI looks really good but the price is just too much ATM. I also don't want a subscription based software. I will appreciate your feedback. Thanks so much for helping. I was starting to get frustrated

What you have is an equirectangular projection, but with the top part cropped. If you change the canvas to a 2:1 ratio (extendiung the top of the image) and fill in the 'missing' top with something (so the horizon is dead centre)it should work, but the sky will have a strange disk hovering in it.

PTGUI is expensive, but very good. I'm using an old version that still works perfectly. (Newer version have features I'd like, but not worth the money to me.)

Check out Panovolo, as suggested above. You can download a trial version and see what it does, then decide if the $30 is worth it to you. I was considering getting it, but my computer is too old to run it.



[rawman001]

Heya Guys I am trying to simply create a 360 photo to start sharing them on FB. I use the Mavic 3 OG to capture the photos- put them in Luminar Neo to stitch and then export as a Jpeg. The problem i have is that the final 360 photo comes out cylindrical the horizon is curved and I am not sure how to fix it. I just can rap my head around this. Can you guys help me with this? I have attached a 360 test photo that was stitched with LN

Not sure if this is helpful or not. I uploaded it to Kuula and this is what it looks like:

Test 360 Not my image, Image by redserv, MavicPilots.com

Test 360 Not my image, Image by redserv, MavicPilots.com

kuula.co

What were you trying to get? I'm new at 360 photos so not really sure what the end result you are looking for is.



[redserv]

What you have is an equirectangular projection, but with the top part cropped. If you change the canvas to a 2:1 ratio (extendiung the top of the image) and fill in the 'missing' top with something (so the horizon is dead centre)it should work, but the sky will have a strange disk hovering in it.

PTGUI is expensive, but very good. I'm using an old version that still works perfectly. (Newer version have features I'd like, but not worth the money to me.)

Check out Panovolo, as suggested above. You can download a trial version and see what it does, then decide if the $30 is worth it to you. I was considering getting it, but my computer is too old to run it.

Not sure if this is helpful or not. I uploaded it to Kuula and this is what it looks like:

Test 360 Not my image, Image by redserv, MavicPilots.com

Test 360 Not my image, Image by redserv, MavicPilots.com

kuula.co

What were you trying to get? I'm new at 360 photos so not really sure what the end result you are looking for is.

Hey man thanks for uploading it. I am basically looking for software that will give a decent stitch and maybe fill the sky line so when I upload to Facebook the final product look some what like what you uploaded to Kuula



[MS Coast]

Heya Guys I am trying to simply create a 360 photo to start sharing them on FB. I use the Mavic 3 OG to capture the photos- put them in Luminar Neo to stitch and then export as a Jpeg. The problem i have is that the final 360 photo comes out cylindrical the horizon is curved and I am not sure how to fix it. I just can rap my head around this. Can you guys help me with this? I have attached a 360 test photo that was stitched with LN

You need to use an appropriate viewer software to see the image. Try Pangazer. It's a free download offered by a member of this forum.



[redserv]

What you have is an equirectangular projection, but with the top part cropped. If you change the canvas to a 2:1 ratio (extendiung the top of the image) and fill in the 'missing' top with something (so the horizon is dead centre)it should work, but the sky will have a strange disk hovering in it.

PTGUI is expensive, but very good. I'm using an old version that still works perfectly. (Newer version have features I'd like, but not worth the money to me.)

Check out Panovolo, as suggested above. You can download a trial version and see what it does, then decide if the $30 is worth it to you. I was considering getting it, but my computer is too old to run it.

Thanks for your advice man. Should I be looking for software that will do an auto sky fill??



[redserv]

You need to use an appropriate viewer software to see the image. Try Pangazer. It's a free download offered by a member of this forum.

Thank you man will look into that



[MS Coast]

Thank you man will look into that

Here's the download link.

PanGazer - download

speleotrove.com



[redserv]

Here's the download link.

PanGazer - download

speleotrove.com

Thank you



[Robert Prior]

Thanks for your advice man. Should I be looking for software that will do an auto sky fill??

I do it by hand. I don't know how Panovolo handles it, but you could ask them (they posted on this thread).



[redserv]

try PanoVolo )

Can you use my uploaded 360 image as a test and show me what it looks like after using Panovolo? Does it fill the sky automatically?



[PanoVolo]

Can you use my uploaded 360 image as a test and show me what it looks like after using Panovolo? Does it fill the sky automatically?

we don't fill the sky (yet) sorry



[redserv]

we don't fill the sky (yet) sorry

Ok thank you



[Robert Prior]

Can you use my uploaded 360 image as a test and show me what it looks like after using Panovolo? Does it fill the sky automatically?

Panovolo takes the individual photos and stitched them into a panorama (doing a better job than the drone does). You'll need to make those individual files available.

Or you could download it and try yourself, which I suggest you do. My Mini 3 Pro manages to cover most of the sky, so there's only a narrow strip at the zenith that I need to fill in by hand. I use Affinity Photo for that because it lets me edit spherical images and the inpainting tool works well on skies.

Affinity Photo – award-winning photo editing software

The only fully-loaded photo editor integrated across macOS, Windows and iPad, Affinity Photo is the first choice of millions of professionals around the world.

affinity.serif.com



[Fizzbang]

Heya Guys I am trying to simply create a 360 photo to start sharing them on FB. I use the Mavic 3 OG to capture the photos- put them in Luminar Neo to stitch and then export as a Jpeg. The problem i have is that the final 360 photo comes out cylindrical the horizon is curved and I am not sure how to fix it. I just can rap my head around this. Can you guys help me with this? I have attached a 360 test photo that was stitched with LN

Here is your image resized 2:1 using GIMP with blank zenith.
View attachment Test 360 Resized.jpg
However there is not a full 360 degree coverage; hence the fold near the penalty area. Otherwise it projects as a full pano in RICOH THETA.
I would use SkyFill to add the missing sky to your image. (I have not done so here.)
