RC Pro antenna replacement

kodiak

Well-Known Member
Joined
Nov 14, 2021
Messages
110
Reactions
69
Location
northern latitudes
Due to a careless mistake on my part I managed to break one of my antennas. The break is right at the joint between the swivel mount and antenna body. The mini-coax solder joint to the antenna PCB is visible and intact, thankfully. After some testing it appears to be mostly a cosmetic issue for now. I still seem to have normal range and function. But it is weak overall and unfolding the antenna is now a delicate affair. These antenna parts are available and I have one on order. Wondering if anyone has done a swap like this and has any insights?

Thanks!

Try here. The part you need will need to be separated from the hinge base. It has a detent area that holds it in place. That area is visible in your picture. A little heat from a hair dryer will make plastic a bit more playable for the removal. They need to be persuaded to get them apart.

  • Like
Reactions: michaeldallen1
Thanks for that. I did order the part from them. After looking into what's involved with the disassembly of the RC Pro I'm hoping I can just swap the antenna cover as you mention. We'll see.

The trick is holding the swivel/hinge base while pulling and prying the upper piece off. You also need to not damage the antenna board in this process. The board itself may be glued to the inside. Take your time.
